Stirrer Plate 6-position

PSVDCMSP06-HR
Stirrer Plate 6-position


Product number     PSVDCMSP06-HR
OEM reference     58-001-420
OEM     Universal
Show only     Stirplates

(Control unit sold separately)

Ultra flat, wear-free magnetic stirrer with with 6 stirring positions, suitable for 6 x 1,000 ml Erlenmeyer flasks, stirring point distance 130 mm

6 stirring positions, 100% maintenance-free and wear-free by inductive Magnetic-Drive concept for powerful mixing of solutions, power reserves up to 3,000 ml per stirring point, 100% synchronized speeds, jerk-free stirring even at low speeds.
Fully encapsulated and hermetically sealed stainless steel housing, IP68, water-, dust-, and germproof, extremely robust construction and performance, easy to clean and maximum resistance, submersible in water- resp. oil baths, suitable for the use in CO2-incubators and ovens.
Technical Parameters of 6 position stirplate
 Stirring points   6
 Stirring point distance  130mm
 Stirring volume  1 - 3000mL
 Stirring power  40 Watt
 Material housing  Stainless Steel
 Permitted operation conditions    -10 up to +50 °C in air, up to +50 °C in water submerged
 Dimensions  245 x 375 x 38mm
 Protection category  IP68
 Weight (gross)  ± 8.9kg
