Epoxy EC, K=0.56, 12x120mm, 30 Kohm NTC
QC4440T
Epoxy EC, K=0.56, 12x120mm, 30 Kohm NTC
Epoxy EC, K=0.56, 12x120mm, 30 Kohm NTC
| Product number | QC4440T |
| Application type |
|
| Cable length | 1.8 |
| Temperture (°C) | 0-70 |
| Max. shaft length (mm) | 120 |
| Shaft diameter (mm) | 12 |
| Shaft material | Epoxy /316SS |
| Cell constant | 0.08 |
| Range | 0.001-500µS/cm |
| Temperature sensor | NTC 30KOhm |
- Designed for use with the ProSense Proline bench meters; ProSense SenseLine handheld meters.
- Nominal cell constant: 0.08.
- Rugged epoxy shaft.
- The risk of carry-over from one sample to another is reduced to a minimum due the special stainless steel design of the QC4440T.
- Applications: Pure and ultra-pure water.
| Conductivity electrode | QC4440T |
| Range | 0.001..500 µS/cm |
| Temperature range (°C) | 0..70 |
| Shaft material | Epoxy / 316SS |
| Shaft diameter (mm) | 12 |
| Shaft length (mm) | 120 |
| Cell type | 316SS poles |
| Cell constant (cm-1) | 0.08 |
| Cable length (m) | 1.8 |
| Connector | LTW (IP67) |
| ATC | NTC 30kOhm |
